Joven

JVA-50IB Vertical Storage Water Heater

RM 835.00

RM 1,045.00 -20%
  • Copper sheathed for higher efficiency
  • High power for performance
  • Low watt density for faster heating efficiency and reliability
  • Easy to replace design
  • Electro-galvanised steel with anti-corrosion treatment
  • An extra outer layer of durable high temperature baked epoxy coating
  • High quality flame retardent ABS plastic
  • Easy access for service


Product Variation


Product Description





Stainless Steel Heater Tank for Rust Free Water



  • Premium quality grade stainless steel heater tank which ensures constantly clean water flow







CFC Free High Density Polyurethane Foam



  • CFC free high density polyurethane foam provides maximum heat insulation and keeps the water hot for a longer period
  • Saving energy







Adjustable Thermostat



  • Allows temperature adjustment from 'OFF' to 'HIGH' ('LOW'/40 Celcius, 'MEDIUM'/55 Celcius and 'HIGH'/70 Celcius
  • Saving energy











Dual Indicator Light


  • GREEN : Mains
  • RED : Heater





Heating Element


  • Copper sheathed for higher efficiency
  • High power for performance
  • Low watt density for faster heating efficiency and reliability
  • Easy to replace design





Heater Enclosure


  • Electro-galvanised steel with anti-corrosion treatment
  • An extra outer layer of durable high temperature baked epoxy coating





Installation Cover


  • High quality flame retardent ABS plastic
  • Easy access for service





Inlet, Outlet or Drain Connection


  • ø15mm (1/2" BSP)





Thermometer


  • Indicates hot water in the heater tank





Adjustable Thermostat


  • Allowing water temperature adjustment (OFF, LOW/40ºC, MEDIUM/55ºC to HIGH/70ºC)
  • Energy saving









Safety Pressure Relief & Drain Valve


  • Pre-set to 10 bars to prevent tank rupture
  • Built-in drain valve to facilitate water drain out during pressure relief and servicing





Thermostat


  • Adjustable temperature from OFF to HIGH
  • Safety cut-out at 95ºC





Thermal Cut-Off


  • Protects heating element from continuous dry burn (Heater tank not filled with water)
  • Fire hazard protection









Instruction Manual


  • Local language included





Warranty Card


  • Local product warranty included





Expansion Bolt


  • 2 sets to mount unit onto concrete wall





Model

Tank Capacity

Litres

(Imp. Gals)

Dimensions (mm)

Approx. Wt. kg (Empty / Full)

A

B

C

D

E

F

G

H

I

J

JVA25

25

(5.5)

100

393

217

372

121

271

-

316

65

77

12 / 37

JVA35

35

(7.7)

100

393

217

372

121

390

-

316

65

77

14 / 49

JVA50

50

(11.0)

100

393

217

372

121

559

-

316

65

77

17 / 67



 Model

Tank Capacity

Litres

(Imp. Gals)

Time Taken (Min)1

Replacement Rate 43°C Rise

3kW

1.5kW

JVA25

25

(5.5)

20

40

3kW Heating Element

63 Litres (14 Gals) per hour



1.5kW Heating Element

32 Litres (14 Gals) per hour

JVA35

35

(7.7)

30

60

JVA50

50

(11.0)

45

90



Specifications
Design Model Vertical
Storage Tank Capacity (Litres) 50 Litres
